RAL 1005 Honey yellow polyester powder coating welded wire mesh
fence paint
SPECIFICATION:
| Main Material | Polyester resin,barium sulfate,titanium dioxide |
| Surface Type | Gloss,matte,wrinkle,sand grain,antique, Hammer,crocodile skin, wood
effect,candy,chrome,transparent,semitransparent,metallic,and
special pattern |
| Powder Properties | Specific gravity : 1.3 - 1.75 (depend on colors) |
| Average particle size : 35 - 45um |
| Coating Properties | Film thickness(ISO 2178) :60 - 90 μm |
| Coverage:15㎡ based on 60μm |
| Pencil hardness: ASTM D3363,H-2H |
| Adhesion :GB/T 9286-1998,0 grade |
| Bending test:GB/T 6742 ,=<2mm |
| Cupping test:GB/T 9753,>=7mm |
| Direct and reverse impact (ASTM D2794) : > 50kg.cm |
| Salt spray Resistance ( ASTM B117, 1000hrs)(Maximum undercutting ,1
mm ): No blistering or loss of adhesion |
| Heat and moisture test GB/T 1740,>=1000 hours,no change |
| Application Schedule | Applied by : Electrostatic spraying devices |
| Curing schedule :10 minutes at 200 ℃ |
| Advantage | Good adhesion,anti-corrosion,UV resistant, strong coating film, |
| Accurate colors, good leveling |
| Shelf Life | 12 months
|
Key Markets & Applications
AGRICULTURAL & CONSTRUCTION
Grain storage systems;Tractors;Trailers;Cranes;Ploughs;Earth moving
equipment;Fork lift trucks.
APPLIANCE
Gas and electric ranges;Refrigerator doors and shelves;Washing
machines and dryers;Freezers;Water heaters;Vacuum cleaners;Kitchen
appliances;Microwave ovens;Garbage disposals;Dishwashers.
ARCHITECTURAL
Aluminum doors/windows;Curatin walls;Facades;Shutters and
louvers;Bathroom fixtures;Mailboxes;Ornamental Fencing;Aluminum
extrusions;Metal gutters;Downspouts;Guard rails;Structural
steel;Highway signs
AUTOMOTIVE & TRANSPORTATION
Primers;Wheels;Bumpers;Window trims;Door handles;Windshield
wipers;Steering wheels;Radiators;Suspension systems;Oil/air filters
Shock absorbers;Valve covers;Brake assemblies;Luggage racks;Mirror
brackets;Ashtrays;Truck seat frames;Battery trays;Chassis
ELECTRICAL
Motor windings and housings;Transformers;Switch gears;Electric
junction boxes;Electric connectors;Electrical cabinets;Lighting
fixtures
Computers;Telecommunications
FUNCTIONAL
Oil, gas and water transmission pipelines;Reinforcing steel bar
(rebar);Valves;Electric motor windings;Bus bar;Riser pipe;Fire
Hydrants
GENERAL METAL
Playground equipment;Bicycle frames/wheels;Golf carts & clubs;Ski
poles;Exercise equipment;Metal toys & wagons;Fans;Desk
accessories;Wheelchairs;Vending/ice-making machines;gasoline
pumps;toolboxes;Motorcycles;Mopeds;Fire extinguishers;Satellite
dishes
HVAC
Air conditioning
equipment;Heaters;Furnaces;Radiators;Boilers;Ventilation.
LAWN & GARDEN
Lawn mowers;Fertilizer spreaders;Snow blowers;Barbecue
grills;Chainsaws;Garden tools;Wheelbarrows;Edgers;Garden
tillers;Snow Shovels;Patio furniture
OTHER
MDF (medium density fiberboard);Plastic;Glass
